20000 Lumen High Brightness 3D Mapping Large Venue Projector

Brand Name:	SMX
Model Number:	MX-X20000U
MOQ:	1pc
Price:	21500usd/pc
Packaging Details:	Carton
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO,CE

Document:

Product Name:

3LCD Laser Projector

Brightness:

20,000 Lumen

Lens:

Motorized

Resolution:

WUXGA

Contrast:

5,000,000:1

Applictaion:

3D Mapping

Supply Ability:

10000pcs/Monthly

Highlight:

3D Mapping Large Venue Projector

3D Mapping short throw laser 4k projector

Motorized Lens Large Venue Projector

Product Description

20000 Lumen High Brightness 3D Mapping Large Venue Projector

MX-X20000U

20,000 Lumen high brightness
WUXGA Resolution
5,000,000: 1 High Contrast
Manual Lens easy to control
Lens Shift and Keystone Correction Flexible Installation
Multiple input / Output Control Interfaces
Laser light Source 20,000 Hrs lifetime

Application:

Large Venues: Perfect for auditoriums, conference halls, theaters, and other large venues where high brightness and clarity are essential.

Professional Presentations: Ideal for corporate presentations, educational institutions, museums, and other settings where impactful visuals are crucial.

Entertainment: Enhance your movie nights, gaming sessions, or events with stunning visuals that captivate your audience.

20000 Lumen High Brightness 3D Mapping Large Venue Projector 0

Len Shift

Projector lens shift is a feature that allows the optical lens of a projector to be physically moved up, down, left, or right without compromising image quality. This adjustment capability enables users to alter the position of the projected image on the screen without having to physically move the projector itself.

20000 Lumen High Brightness 3D Mapping Large Venue Projector 1

Keystone Correction

Keystone correction is a feature found in many projectors that digitally adjust the shape of the projected image to correct the distortion caused by projecting at an angle. When a projector is not positioned perpendicular to the screen or projection surface, the resulting image may appear trapezoidal or distorted, with the top or bottom of the image wider than the opposite side.

20000 Lumen High Brightness 3D Mapping Large Venue Projector 2

Specification

Model#	MX-X20000U
Brightness
	Brightness(Lumen)	20,000
Overall Spec
Panel	Display Panel	3x1.0"
	Display Technology	Liquid Crystal Display
	Native Resolution	WUXGA (1920 x 1200)
Laser Lifetime	Normal mode	20000hrs
Laser Lifetime	ECO mode	30000hrs
Projection Lens (STD)	Len Model	MX-EG12ZLM
	Zoom/Focus	Motorized
	Throw Ratio (16:10)	1.24-2.01 @100inch
	F	1.8-2.24
	f	27.7-44.3mm
	Zoom Ratio	1.62
	Screen size	60-500 inch
	Lens Shift V	±65%
	Lens Shift H	±25%
CR	Contrast Ratio(Min)	3,000,000:1
Noise	Noise(dB)	Full:46db / Normal:44db / Eco1:43db / Eco2:42db
AR	Aspect Ratio	Native:16:10 Compatible: 4:3/16:9/normal/16:6
Terminal(I/O port)
Input	VGA	*1
	HDMI 1.4(IN)	*2
	USB-A	*1
	USB-B	*1 (Display)
	RJ45	*1 (Display)
	DVI-D	*1
	HD BaseT	*1
	Audio in(mini jack,3.5mm)	*1 (VGA/DVI-D share)
	DMX512	*1
Output	HDMI 1.4(OUT)	*1
Output	Audio out (mini-jack,3.5mm)	*1
Control	RS232C (Input)	*1
	RS232C (Output)	*1
	Wired Remote(IN)	*1
	Wired Remote(OUT)	*1
Other Functions
Keystone	Keystone Correction	V: ±30° H:±30° Pincushion/Barrel Correction 6 Corner Geometry correction Grid ImageTune correction
OSD	Languages	26 languages: English, German, French, Italian, Spanish, Polish, Swedish, Dutch, Portuguese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian, Arabic, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazak, Vietnamese, Thai, Farsi
LAN Control	LAN Control-RoomView (Crestron)	Yes
	LAN Control-AMX Discovery	Yes
	LAN Control-PJ Link	Yes
Display Resolution	Computer Signal Input	VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K@30Hz
Others	360° projection	360° Install
Others	Edge Blending	Yes
Dimension&Weight
	Product Size (WxHxD mm)	599X240.2X493.8mm (not including lens)
	Net. Weight (KG)	28.9Kg (not including lens)
Accessory
	Manual Languages	Chinese, English
	Standard Accessories	Power cord (3m, Black), Remote control

Product Details

20000 Lumen High Brightness 3D Mapping Large Venue Projector 3
