5000 Lumen UST Laser Projector Laser TV WUXGA for Home Cinema

All Category

3D Projection Mapping Projector

Immersive Projection Projector

DLP Laser Projector

Miss. May Wei

may@smxdisplay.com

+86 18923801593

+86 18923801593

Contact Now

5000 Lumen UST Laser Projector Laser TV WUXGA for Home Cinema

Brand Name:	SMX
Model Number:	MX-WPL500U
MOQ:	1pc
Packaging Details:	Carton
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO,CE,RoHS

Document:

Model:

UST Laser Projector

Brightness:

5000 Lumens

Speaker:

Built-in 16W

Contrast Ratio:

Up To 100,000:1

Connectivity:

HDMI, USB, VGA

Lamp Life:

Up To 20,000 Hours

Resolution:

WUXGA

Throw Ratio:

0.235:1

Technology:

Supply Ability:

10000pcs/Monthly

Highlight:

20000 Hours Lifetime Ust 4k Projector

20000 Hours Lifetime 4k ust laser projector

XGA Ust 4k Projector

Product Description

5000 Lumen UST Laser Projector Laser TV WUXGA for Home Cinema

Bring the cinematic experience home with the SMX MX-WPL500U Ultra Short Throw Laser Projector — a premium solution for movie lovers, gamers, and home entertainment enthusiasts. With brilliant 5000 lumens of brightness, WUXGA (1920x1200) resolution, and advanced laser technology, this projector delivers stunning image quality in virtually any room, regardless of lighting.

The Laser Light Source doesn't need maintenance for 20,000 hours, and the projector is energy-efficient to save resources.

Project Large Images in Rooms with Limited SpaceBig Pictures with Fewer ShadowsShare large 80-120-inch images in rooms of any size, from small huddle rooms to hybrid classrooms where installation space on the ceiling is limited.

Key Features:

5000-Lumen Brightness
Delivers vivid, lifelike visuals even in rooms with ambient light.
WUXGA Resolution (1920×1200)
Offers crisp, widescreen clarity ideal for high-definition content.
Ultra Short Throw (UST) Design
Projects large images from a very short distance—no ceiling mounts or long cables required.
Advanced Laser Light Source
Provides up to 20,000+ hours of maintenance-free performance with consistent brightness and color.
True Home Cinema Experience
Rich contrast, smooth motion, and immersive color reproduction make every movie night unforgettable.
Built-In Audio Support
Enjoy powerful sound without the need for external speakers.

Perfect For:

Home theater setups
Living room entertainment
Gaming on the big screen
Streaming and sports viewing

5000 Lumen UST Laser Projector Laser TV WUXGA for Home Cinema 0

Laser TV Combine = UST Laser Projector + ALR Screen

5000 Lumen UST Laser Projector Laser TV WUXGA for Home Cinema 2

Specification:

Model No.	MX-WPL500U
	Lumen	5000
	Resolution	WUXGA
	Light source	Laser
Overall Spec
Panel	Display Panel	3x0.64” with MLA
	Display Technology	Liquid Crystal Display
	Native Resolution	WUXGA (1920 x 1200)
Light Source Lifetime	Normal mode	20000hrs
	ECO mode	≥20000hrs
	ECO2 mode	30000hrs
Projection Lens	F	F1.7
	f	2.94mm
	Lens Vendor	RICOH
	Zoom/Focus	Manual
	Throw Ratio	0.235:1
	Screen size	80-150
CR	Contrast Ratio	5000000:1
Noise	Noise(dB)	37dB(Normal) 30dB(ECO1) 27dB(ECO2)
Uniformity	Uniformity(Actual Min) -JISX6911	80%
AR	Aspect Ratio	Native:16:10 Compatible: 4:3/16:9
Terminal(I/O port)
Input	VGA	*1
	HDMI 1.4B(IN)	*2
	USB-A	*1
	USB-B	*1(Display)
	RJ45	*1(Display)
	Audio in (mini jack,3.5mm)	*1
Output	VGA	*1
Output	Audio out (mini-jack,3.5mm)	*1
Control	RS232	*1
	RJ45	*1 (Control)
	USB-B	*1 (For upgrade)
General Spec
Audio	Speaker	16W*1
Keystone	Keystone Correction (Lens@center)	V: ±5° H:±5° Pincushion/Barrel Correction 6 Corner Geometry correction Grid image tune
LAN Control	LAN Control-RoomView (Crestron)	Yes
	LAN Control-- AMX Discovery	Yes
	LAN Control-- PJ Link	Yes
Others	360° projection	Yes
Dimension&Weight
	Product Size (WxHxD mm)	520x435x168
	Net. Weight (KG)	11
	Packaging (WxHxD mm)	610526266
	Gross. Weight (KG)	13.5
Accessory
	Manual Languages	Chinese, English
	Standard Accessaries	Power cord, Remote control, HDMI Cable
