8200 Lumen 3LCD Laser Projector For Large Venue Vivid Projection

Brand Name:	SMX
Model Number:	MX-VL820U
MOQ:	1Pc
Packaging Details:	Carton Package
Payment Terms:	T/T

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO，CE，RoHS

Product Name:

Immersive Projector

Brightness:

8,200 Lumen

Resolution:

1920*1200

Display Technology:

Light Source:

Laser

Contrast:

5,000,000:1

Throw Ratio:

1.08-1.76

Zoom Ratio:

Lens Shift:

V: 0%~45%, H: ±21%

Projection Size:

30-300 Inch

Language:

26 Languages

Supply Ability:

100000pcs/monthly

Highlight:

WUXGA 3LCD Laser Projector

WUXGA 3lcd home projector

8200 Lumen 3LCD Laser Projector

Product Description

MX-VL820U WUXGA 8200 Lumen High Brightness LCD Laser Projector

8200 Lumen 3LCD Laser Projector For Large Venue Vivid Projection 0

The SMX's MX-VL820U is a high-brightness laser projector with 8200 lumens brightness, designed for commercial, educational and public spaces. With a lifespan of up to 20,000 hours, it can project ultra-large screens up to 300 inches in WUXGA resolution. Equipped with features such as H/V lens shift, 1.6x optical zoom, advanced keystone correction and 360° projection function, this projector provides flexible setup options.

Key Features:

8,200 Lumens
5,000,000:1 High Contrast
Throw Ratio: 1.08-1.76
Lens Shift : V: 0%-45%, H: ±21%
20,000 Hours Ultra-long Laser Lifespan
Advanced Keystone Correction
Built in 16W speaker
Edge Blending Support
360 Degree Flexible Projection
WUXGA Native High Resolution
Adaptable to any environment
4K Signal Supported

Application Area:

Public Space
Hologram Projection
Immersive Projection
Commercial Display
Large Venue
Art Exhibition&Museum

Fits Any Environment

The SMX's MX-VL820U features tool-free lens shift control, 1.6x optical zoom, H/V ±30° keystone correction, 6-corner geometry correction and 4-corner adjustment options to adjust the image without shifting, ensuring it fits in any environment.

8200 Lumen 3LCD Laser Projector For Large Venue Vivid Projection 1

WUXGA Native Resolution

8200 Lumen 3LCD Laser Projector For Large Venue Vivid Projection 2

8200 Lumen 3LCD Laser Projector For Large Venue Vivid Projection 3

8200 Lumen 3LCD Laser Projector For Large Venue Vivid Projection 4

8200 Lumen 3LCD Laser Projector For Large Venue Vivid Projection 5

8200 Lumen 3LCD Laser Projector For Large Venue Vivid Projection 6

Specification

	Model No.	MX-VL820U
	Brightness(Lumen)	8200
	Resolution	WUXGA
	Light source	NICHIA LASER
Overall Spec
Panel	Display Technology	Liquid Crystal Display
Panel	Native Resolution	WUXGA (1920 x 1200)
Light source Life time	Full Normal/Normal mode	20000hrs
	ECO1 mode	30000hrs
	ECO2 mode	30000hrs
Projection Lens	F	1.58-2.02
	f	15.3mm-24.6mm
	Zoom/Focus	Manual
	Throw Ratio	1.08 (wide)-1.76 (tele)
	Zoom Ratio	1.6
	Screen size	30-300 inch
	Lens Shift	V:＋45%～0%, H:±21%
CR	Contrast Ratio (FOFO)	5000000:1
Noise	Noise(dB) *1	39dB(Normal) 31dB(ECO1) 29dB(ECO2)
Uniformity	Uniformity(Actual Min) -JISX6911	80%
AR	Aspect Ratio	Native:16:10 Compatible: 4:3/16:9
Terminal(I/O port)
Input	VGA	*1
	HDMI 1.4B(IN)	*2
	USB-A	*1
	USB-B	*1 (Display)
	RJ45	*1 (Display)
	HD BaseT	*1(Optional)
	Audio in (mini jack,3.5mm)	*1
Output	VGA	*1
Output	Audio out (mini-jack,3.5mm)	*1
Control	RS232	*1
	RJ45	*1 (Control)
	USB-B	*1 (For upgrade)
General Spec
Audio	Speaker	16W*1
Dust filter		W/Filter
Filter Life time		8000h
Power Consumption	Power Requeirements	100~240V@ 50/60Hz
	Power Consumption (Normal) (Max)	425
	Power Consumption (ECO1) (Max)	285
	Power Consumption (ECO2) (Max)	235
	ECO Standby Mode Power Consumption	<0.5W
Temp.&Humidity	Operating Temp.	0m≤Altitude≤1700m, Ambient 0°C~50°C
	Operating Temp.	1700m＜Altitude＜3000m, Ambient 0°C~40°C
	Operating humidity.	20-85%
	Store Temp.	-10 to 50°C
	High altitude	0~3000m
Other Functions
Keystone	Keystone Correction (Lens@center)	V: ±30° H:±30° Pincushion/Barrel Correction 6 Corner Geometry correction 4 Corner Correction Grid image tune
OSD	Languages	26 languages: English, German, French, Italian, Spanish, Polish, Swedish, Dutch ,Portugese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian, Arabic, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazak,Vietnamese,Thai, Farsi
LAN Control	LAN Control-RoomView (Crestron)	Yes
	LAN Control--AMX Discovery	Yes
	LAN Control--PJ Link	Yes
Scanning Frequency	H-Synch Range	15~100KHz
Scanning Frequency	V-Synch Range	24~85Hz
Display Resolution	Computer Signal Input	VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K@30Hz
Display Resolution	Video Signal Input	480i, 480p, 576i, 576p, 720p, 1080i and 1080p
SW setting	Auto Setup	INPUT SEARCH,AUTO PC,Auto Keystone
	Blank	Yes
	Suspend	Yes(5 minutes no signal as default)
	Picture mode	Dynamic,Standard,Cinema, Colorboard,sim-DICOM,Blackboard(Green)
	Cooling time	0s,normal,30s
	Auto Ceiling	Yes
	D-Zoom	1~33
Others	360° projection	Yes
Others	Edge Blending	Yes
Dimension&Weight
	Product Size (mm)	405 (W)358(D)137(H)
	Net. Weight (KG)	~7.9KG
Accessory
	Manual Languages	Chinese,English
	Standard Accessaries	Power cord, HDMI cable,Remote control
