12000 Lumen 3LCD Laser Projector WUXGA for Large Venue Projection

Brand Name: SMX
Model Number: MX-X12000U
MOQ: 1pc
Packaging Details: Carton/Flight Case
Payment Terms: T/T
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
ISO,CE
Document:
SMX 12000 Lumen Laser Proje...on.pdf
Product Name:
3LCD Laser Projector
Birghtness:
12000 Lumen
Contrast:
3000000:1
Display Technology:
3LCD
Light Source:
Laser
Len Shift:
V: +50%，-10% / V: ±20%
Supply Ability:
10000pcs/Monthly
Product Description



12000 Lumen 3LCD Laser Projector WUXGA for Large Venue Projection





12000 Lumen 3LCD Laser Projector WUXGA for Large Venue Projection 0





Application



12000 Lumen 3LCD Laser Projector WUXGA for Large Venue Projection 1





Specification



　Model No. MX-X12000U
Brightness
　 Brightness
(ANSI Lumens )		 12000lumen
Light source Laser
Overall Spec
Panel Display Panel 3x0.76"
Display Technology Liquid Crystal Display
Native Resolution WUXGA (1920 x 1200)
Light source
Lifetime		 Normal mode 20000hrs
ECO mode 20000hrs
Projection Lens Len Type Zoom Lens
Zoom/Focus Manual(Standard Len)
Throw Ratio(16:10) 1.46-2.95
F#(Wide-Tele) 1.7~2.37
f(mm) 24.4-48.6
Zoom Ratio 2
Lens Shift V +50%,-10%
Lens Shift H ±20%
CR Contrast Ratio(Min) 3,000,000:1
AR Aspect Ratio Native:16:10
Compatible: 4:3/16:9/normal
Terminal(I/O port)
Input VGA *1
HDMI 1.4(IN) *2
USB-A *1 (5V/1.5A)
USB-B *1 (Display)
RJ45 *1 (Display)
DVI-D *1
HD BaseT *1
HD-SDI(3G-SDI) Optional
Audio in
(mini jack,3.5mm)		 *1 (VGA/DVI-D share)
Output VGA *1
HDMI 1.4(OUT) *1
Audio out
(mini-jack,3.5mm)		 *1
Control RS232 *1
RJ45 *1 (Control)
USB-B *1 (For upgrade)
Wired Remote(IN) *1
Wired Remote(OUT) *1
Other Functions
Keystone Keystone Correction V: ±30°
H: ±30°
Pincushion/Barrel Correction
6 Corner Geometry correction
Grid ImageTune correction
LAN Control LAN Control-RoomView
(Crestron)		 Yes
LAN Control-AMX Discovery Yes
LAN Control-PJ Link Yes
Others 360° projection 360° Omni bearing installation
Edge Blending Yes
Dimension&Weight
　 MAX Dimensions
(WxHxD mm)		 600*218*503
Net. Weight (KG) ~25kg
Accessory
　 Manual Languages Chinese, English
Standard Accessories Power cord(3m,Black), Remote, HDMI Cable





12000 Lumen 3LCD Laser Projector WUXGA for Large Venue Projection 2



12000 Lumen 3LCD Laser Projector WUXGA for Large Venue Projection 3
