20000 Lumen WUXGA Laser Projector Professional Outdoor 3D Projection Mapping

Brand Name:	SMX
Model Number:	MX-X20000U
MOQ:	1pc
Packaging Details:	Carton/ Flight Case
Payment Terms:	T/T,Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO,CE

Document:

Product Name:

Laser Mapping Projector

Brightness:

20,000 Lumen

Resolution:

WUXGA

Light Source:

Laser

Len Shift:

Keystone Correction:

Lenses:

Motorized

Focus:

Motorized

Supply Ability:

12000pcs/Monthly

Product Description

20000 Lumen WUXGA Laser Projector Professional Outdoor 3D Projection Mapping

Key Features

20,000 Lumen brightness for vivid outdoor projections
WUXGA resolution (1920×1200) for crisp, detailed images
Long-life laser light source (20,000-30,000 hours)
Motorized zoom and focus with lens shift capability
360-degree installation flexibility
Advanced geometric correction and edge blending
Professional-grade connectivity options

Product Overview

The SMX MX-X20000U is a professional-grade laser projector delivering exceptional brightness and image quality for large venues and demanding applications. Its 20,000-lumen output and WUXGA resolution make it ideal for auditoriums, concert halls, museums, and spectacular 3D projection mapping events.

Technical Specifications

Model Number	MX-X20000U
Brightness	20,000 Lumen
Display Technology	3x1.0" Liquid Crystal Display
Native Resolution	WUXGA (1920 × 1200)
Laser Lifetime	20,000 hours (Normal) / 30,000 hours (ECO)
Contrast Ratio	3,000,000:1
Projection Lens (Standard)	MX-EG12ZLM (Motorized Zoom/Focus)
Throw Ratio (16:10)	1.24-2.01 @100inch
Lens Shift	Vertical: ±65% / Horizontal: ±25%
Keystone Correction	Vertical: ±30° / Horizontal: ±30°
Connectivity	HDMI, VGA, DVI-D, HDBaseT, USB, RJ45, DMX512, RS232C

Available Lenses

Model	Type	Throw Ratio	Zoom Ratio	Lens Shift
MX-EG05ZLM	Short Throw 3	0.53-0.65	1.23	V:±50% / H:±20%
MX-EG06ZLM	Short Throw 2	0.65-0.87	1.34	V:±55% / H:±20%
MX-EG08ZLM	Short Throw 1	0.86-1.25	1.45	V:±65% / H:±25%
MX-EG12ZLM	Standard	1.24-2.01	1.62	V:±65% / H:±25%
MX-EG20ZL	Long Throw 1	1.98-3.95	1.99	V:±65% / H:±25%
OL-EG39ZLM	Long Throw 2	3.95-7.50	1.90	V:±65% / H:±25%

Product Images
