Laser Alchemy Turning 6500 Lumens Projector Drama Support 4K-WUXGA Sorcery

Brand Name:	SMX
Model Number:	MX-SL6500U
MOQ:	1
Price:	USD 2480/PC
Packaging Details:	19.37x17.44x9.4 inch with carton
Payment Terms:	T/T, Western Union

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

CE,ROHS

Light Source:

Laser Light

Life Time:

20000Hrs

Business & Education, Home

Technology:

Laser

Picture Size:

55-300 Inch

Throw Ratio:

0.44:1

Standby Mode:

Normal/ECO

Dimensions:

15.9 X 15.9 X 6.4 Inches

Lens:

Manual Focus

Len Shift:

V: ±15° H：±15°

Dynamic Contrast Ratio:

5,000,000:1

Supply Ability:

10000 PCS/month

Highlight:

4K-WUXGA Laser Alchemy Turning Projector

6500 Lumens Laser Alchemy Turning Projector

Drama Support Laser Alchemy Turning Projector

Product Description

Witness the dark arts of optical engineering. We've alchemized 6500 laser lumens short throw into a spectrum that breathes – searing whites that don't bloom, blacks that swallow stray photons. The WUXGA DMD chip orchestrates 2 million micromirrors dancing at 9,000Hz, while 4K signals are dissected with AI sharpening. That 500,000:1 contrast? It's not measured, it's felt – in the goosebumps as a horror movie shadow detaches from your wall, or when CAD blueprints reveal hidden stress fractures. Magic is just science with better PR.

Laser Alchemy Turning 6500 Lumens Projector Drama Support 4K-WUXGA Sorcery 0

Specifications

Model		MX-SL6500U
	Light source	Laser-NUBM36*1(105W)
	Mainchip	Topaz Prime PWC895
	Sony IC	CXD3555+CXA3861(1+3)
Brightness
	Brightness(Lumen)	6500
Overall Spec
Panel	Display Panel	3x0.64” with MLA
	Display Technology	Liquid Crystal Display
	Native Resolution	WUXGA (1920 x 1200)
Light source Life time	Normal mode	20000hrs
	ECO1 mode	30000hrs
	ECO2 mode	30000hrs
Lens	Lens Vendor	RICOH
Projection Lens	F	F1.6
	f	6.39mm
	Zoom/Focus	Manual
	Throw Ratio	0.44:1
	Zoom Ratio	N/A
	Screen size	55-300 inch
	Lens Shift	N/A
CR	Contrast Ratio (FOFO)	5000000:1
Noise	Noise(dB)	TGT: 37dB (Normal) 27dB (ECO)
Uniformity	Uniformity(Actual Min) -JISX6911	80%
AR	Aspect Ratio	Native:16:10 Compatible: 4:3/16:9
Terminal(I/O port)
Input	VGA	*1
	HDMI 1.4B(IN)	*2
	USB-A	*1
	USB-B	*1(Display)
	RJ45	*1 (Display)
	DVI-D	N/A
	HD BaseT	*1 (Optional)
	HD-SDI(3G-SDI)	N/A
	Video	N/A
	Audio in (mini jack,3.5mm)	*1
Output	VGA	*1
	HDMI 1.4B(OUT)	N/A
	Audio out (mini-jack,3.5mm)	*1
Control	RS232	*1
	RJ45	*1 (Control)
	USB-B	*1 (For upgrade)
	Wired Remote(IN)	N/A
	Wired Remote(OUT)	N/A
General Spec
Audio	Speaker	16W*1
Dust filter		W/Filter
Filter Life time		8000h
Power Consumption	Power Requeirements	100~240V@ 50/60Hz
	Power Consumption (Normal) (Max)	360
	Power Consumption (ECO1) (Max)	280
	Power Consumption (ECO2) (Max)	230
	ECO Standby Mode Power Consumption	<0.5W
Temp.&Humidity	Operating Temp.	0 to 40°C
	Operating Thumidity.	20-80%
	Store Temp.	-10 to 50°C
	High altitude	0~3000m
Other Functions
Keystone	Keystone Correction (Lens@center)	V: ±15° H:±15° Pincushion/Barrel Correction 6 Corner correction 4 Corner Correction Grid image tune
OSD	Languages	26 languages: English, German, French, Italian, Spanish, Polish, Swedish, Dutch ,Portugese, Japanese, Simplified Chinese, Traditional Chinese, Korean, Russian, Arabic, Turkish, Finnish, Norwegian, Danish, Indonesian, Hungarian, Czech, Kazak,Vietnamese,Thai, Farsi
LAN Control	LAN Control-RoomView (Crestron)	Yes
	LAN Control-- AMX Discovery	Yes
	LAN Control-- PJ Link	Yes
Scanning Frequency	H-Synch Range	15~100KHz
Scanning Frequency	V-Synch Range	24~85Hz
Display Resolution	Computer Signal Input	VGA, SVGA, XGA, SXGA,WXGA,UXGA,WUXGA,4K@30Hz
Display Resolution	Video Signal Input	480i, 480p, 576i, 576p, 720p, 1080i and 1080p
SW setting	Auto Setup	INPUT SEARCH,AUTO PC,Auto Keystone
	Blank	Yes
	Suspend	Yes(5miniutes no singnal as default)
	Picture mode	Dynamic, Standard, Cinema, Colorboard, sim-DICOM, Blackboard(Green)
	Cooling time	0s, Normal,30s
	Closed caption	N/A
	Auto Ceiling	Yes
	D-Zoom	1~33
Others	360° projection	Yes
Dimension&Weight
	MAX Dimensions (WxHxD mm)	405(W)×404(D)×164(H)
	Net. Weight (KG)	8.1kg
	Packaging Box Dimensions (WxHxD mm)	510(W)×498(D)×260(H)
	Gross. Weight (KG)	~10.4KG
Accessory
	Manual Languages	Chinese,English
	Standard Accessaries	Power cord (EU)/power cord (Ja) Remote control&RC Battery
Regulation List
China	CCC	√
WW	CB	√
US	cTUVus	√
	FCC	√
	FDA	√
EU	CE-EMC	√
	CE-LVD	√
	CE-ERP	√
Laser Security Level	class1	√
EMC Class
	EMC Class	Class A@3dBm
