| Brand Name: | SMX |
| Model Number: | MX-LK6500 |
| MOQ: | 1 |
| Payment Terms: | T/T |
| Supply Ability: | 10000pcs/month |
| Model No. | MX-LK6500 |
| Brightness | |
| Brightness (Lumen) | 6500 |
| Overall Specifications | |
| Display Panel | 3x0.64" with MLA |
| Display Technology | Liquid Crystal Display |
| Native Resolution | 4K Enhancement |
| Light Source | |
| Lifetime (Full/Normal mode) | 20000hrs |
| Lifetime (ECO mode) | 30000hrs |
| Lens | |
| F | 1.5~2.08 |
| f | 17.2~27.7mm |
| Zoom/Focus | Manual |
| Throw Ratio | 1.2 (wide)-2.0 (tele) |
| Zoom Ratio | 1.6 |
| Screen size | 30-300 inch |
| Lens Shift | V:＋0%~66% H: ±29% |
| Performance | |
| Contrast Ratio | 5,000,000:1 |
| Noise (dB) | 39dB(Normal) 28dB(ECO) |
| Uniformity (Actual Min) | 80% |
| Aspect Ratio | Native:16:9 Compatible: 4:3/16:10 |
| Terminal (I/O Port) | |
| Input | HDMI 2.1(IN) *2 USB-A *2 RJ45 *1 HD BaseT *1(Optional) |
| Output | Audio port S/PDIF*1 Audio out (mini-jack,3.5mm) *1 |
| Control | RS232C *1 RJ45 *1 (Control) |
| General Specifications | |
| Speaker | 16W*1 |
| Other Functions | |
| Keystone Correction | V: ±30° H: ±25° 4 Corner Correction |
| OSD Languages | English, Chinese |
| LAN Control (PJ Link) | Yes |
| Display Resolution | up to 3840x2160/60Hz |
| SW Setting | D-Zoom: YES (HDMI) Auto Ceiling: Yes HDR10 Support 360° free viewing Support |
| Dimensions & Weight | |
| MAX Dimensions (WxDxH mm) | 405 (W)*358(D)*137(H) |
| Net Weight (KG) | ~7.8KG |
| Accessories | |
| Manual Languages | Chinese, English |
| Standard Accessories | Power cord (EU)/power cord (Ja)/Remote control |
