| Brand Name: | SMX |
| Model Number: | MX-361XS |
| MOQ: | 10pcs |
| Payment Terms: | ,T/T,Western Union |
| Supply Ability: | 10000pcs/monthly |
3500 Lumens Video Projector with XGA for Classroom Meeting Room Projection
The SMX Classroom Projector is purpose-built to deliver vibrant, attention-holding visuals in any educational environment. With a bright 3,500 ANSI lumens output and advanced 3LCD imaging technology, it produces stunningly clear, colour-rich images even in well-lit rooms. Designed for daily use, it combines essential connectivity like dual HDMI ports with professional control options to create a seamless, integrated presentation system for teachers and IT administrators alike.
Key Features & Benefits:
• Brilliant, Readable Imagery: The 3LCD optical engine ensures full-time colour projection and superior light efficiency, eliminating the "colour break-up" effect seen in other technologies. With XGA (1024x768) resolution, it perfectly matches common educational content and digital whiteboards, delivering sharp text, detailed diagrams, and true-to-life colours that keep every student engaged.
• Classroom-Ready Brightness: 3,500 lumens of high brightness cut through ambient light from windows and overhead lamps, ensuring presentations, videos, and lesson materials are always clearly visible from the front to the back of the room.
• Unmatched Connectivity & Compatibility:
• Dual HDMI Ports: Connect and quickly switch between two modern media sources simultaneously—such as a document camera and a laptop, or a computer and a streaming device—without swapping cables.
• USB-A Port: Display content directly from a USB flash drive and power media players, eliminating the need for a separate computer. Also supports USB mouse control for added convenience.
• RS232 Control Port: Enables advanced system integration. IT staff can centrally manage, schedule, and control the projector via room control systems (Crestron, AMX, Extron) or simple serial commands, facilitating school-wide management and automation.
• Designed for Durability & Ease: A robust design ensures long-term reliability. Features like quick startup/shutdown, intuitive on-screen menus, and flexible installation options (front/rear, table/ceiling) make it a hassle-free addition to any learning space. A long-life lamp keeps the total cost of ownership low.
Ideal For:
• K-12 and Higher Education Classrooms
• Training Rooms and Lecture Halls
• Conference Rooms and Meeting Spaces
• Any environment requiring a dependable, high-brightness projector with professional control.
Specification
| Model | ||
| Model No. | MX-351XS | |
| Resolution | XGA | |
| Brightness | ||
| ISO | Brightness ( Ansi Lumens ) |
3500 |
| Overall Spec | ||
| Panel | Display Panel | 3x0.63” |
| Display Technology | Liquid Crystal Display | |
| Native Resolution | XGA (1024x768) | |
| Projection Lens |
Zoom/Focus | Manual |
| Throw Ratio | 60"@1.8m；1.47~1.77:1 | |
| F | F:2.1~2.25 | |
| f | f=19.109~22.936mm | |
| Zoom Ratio | 1.2x optics | |
| Screen size | 0.887~10.899m(30"~300") | |
| Contrast | Contrast Ratio(Min) | 15000:1 (w/o IRIS) |
| Noise | Noise(dB)@1m | ECO: 35dB Normal: 38dB |
| Uniformity | Uniformity(Actual Min) -JISX6911 |
80% |
| AR | Aspect Ratio | 4:3 (Standard)/16:9(Compatible) |
| Terminal(I/O port) | ||
| Input | HDMI | *2 |
| USB-A | *1 | |
| Control | RS232 | *1 |
| General Spec | ||
| Audio | Speaker | N/A |
| Power Consumption | Power Requirements | 100~240V@ 50/60Hz |
| Power consumption (W) |
300 | |
| Power Consumption (ECO) |
250 | |
| ECO Standby Mode Power Consumption |
<0.5W | |
| Cooling Set Up | Operating Temp. | 5℃~40℃(35~ ECO) |
| Store Temp. | -10℃~~50℃ | |
| Operating Humidity | 20%~80% | |
| High altitude | 0 to 3000 m | |
| Other Functions | ||
| Keystone | Keystone Correction | V: ±30°/ H:±30° 4 corner (Manual) |
| OSD | Languages | 9 languages: English / Chinese / French / Spanish/ Portuguese / Korean/ Russian /Vietnamese/Arabic |
| Scanning Frequency | H-Synch Range | 15~100KHz |
| V-Synch Range | 48~85Hz | |
| Display Resolution | Computer Signal Input | VGA, SVGA, XGA, SXGA, WXGA, UXGA, WUXGA, Mac |
| SW setting | Auto Setup | INPUT SEARCH |
| Suspend | No signal to Power Off | |
| Picture mode | Dynamic,Standard,Cinema,Blackboard,Colorboard | |
| Lamp mode | NORMAL, ECO | |
| Filter Cleaning Cycle | 200/500/1000 hours | |
| Cooling time | 0S,60s | |
| D-Zoom | 300% | |
| Others | Customizable multi-function keys | |
| Dimension&Weight | ||
| MAX Dimensions (WxHxD mm) |
345*261*99 | |
| Net. Weight (KG) | ~3.1 | |
| Packaging Size (WxHxD mm) |
442*368*195 | |
| Gross. Weight (KG) | 4.5 | |
| Accessory | ||
| Standard Accessaries | Power cord, HDMI cable, Remote control | |
